TOP-DRILL トップ-ドリル

Next generation indexable drill

» Remarkable machinability with high stability
» Twisted coolant channels: Improved chip evacuation and hole quality
» Applicable to a variety of materials
» Enhanced insert durability with new grade (TT9080)
» One insert for both internal and external pockets

Next Generation Indexable Drill

TaeguTec’s true 4 corner inserts are suitable for both internal/external pockets while reducing inventory and promoting cost reduction. The holder’s prominent flute shape with helix type internal coolant ensures smooth chip evacuation and machining stability. Ideally configured cutting edges enable optimum chip control by minimizing cutting loads and ensures remarkable machining performance on all materials.

ホルダー

チップ・材質

​TT9080 (PVDコーティング)

  • 鋼の一般加工用
  • ステンレス鋼の一般加工用
  • 耐熱合金の一般加工用

​TT9300 (CVDコーティング)

  • 炭素鋼・合金鋼の高速加工用

TT8020 (PVDコーティング)

  • 鋼の粗断続加工用
  • ステンレス鋼の粗断続加工用
  • 耐熱合金の低速・断続加工用
